Name: Resolution 64x128 0.96'' OLED Display Module Transparent Support 12C/4 - Wire Spi
Brand: Elite Tree Technology
SKU: ET096OL01
Price: 2.20 USD
Availability: InStock

Home Products OLED Display Module

Resolution 64x128 0.96'' OLED Display Module Transparent Support 12C/4 - Wire Spi

Product Details:

Place of Origin:	China
Brand Name:	Elite Tree
Certification:	ISO9001:2015 / ISO14001
Model Number:	ET096OL01

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiable
Packaging Details:	In anti-statics bag packed in carton or according to the customer's requirement
Delivery Time:	5days for sample and 20-25 days for mass production
Payment Terms:	T/T, Western Union
Supply Ability:	100Kpcs~ per month

Contact Now

Detailed Product Description

Display Type:	OLED Display 0.96'' OLED Display Module	Operting Voltage:	2.6 ~ 3.5V
Operting Temperature:	-40~70C	Storage Temperature:	-40~85C
Driver IC:	SH1107	Color:	Monochrome White
Interface:	12C/4-Wire Spi	Product Name:	OLED Display Module
Highlight:	custom oled display , oled small screen

OLED 0.96'' OLED Display Module 64 * 128 Resolution Transparent Support 12C/4-Wire Spi

OLED Display Module

Product Information

Display Type	0.96'' OLED Display Screen
Screen Size(inch)	0.96”
Display Resolution	64 * 128
Pixel Pitch	0.17mm * 0.17mm
Active Area (mm*mm)	10.86mm * 22.74mm
Outline Dimension (mm*mm)	14mm * 28mm * 1.22mm
Duty	1/28
PIN	13/22
Brightness (nits)	100(Min) cd/m²
Interface	12C/4-Wire Spi

Our advantages

1) Small quantity accepted
2) Competitive price and short lead-time and best service
3) ROHS/ ISO 14001 and other related certificates are available
4) Reply the mail within 24 hours

Application

Autoelectronics, 3D&Shutter, Meters & Instrument, Telecommunication,

Domestic electrical appliance(Household appliance), Fuel dispensers, Smart Watch,

Office equipment, Medical &health equipment, Business related facility, Education electronics, etc.

Outline Drawing

Resolution 64x128 0.96'' OLED Display Module Transparent Support 12C/4 - Wire Spi 0
